Hydraulic cutting tools

SEDA Catalyst Shears

The catalytic converter is one of the most valuable components of an end-of-life vehicle. With SEDA’s recycling shears, it can be removed in just seconds.

SEDA’s recycling shears are ideally suited for the dismantling of catalytic converters and exhaust systems. Developed and optimized by Weber Hydraulics in collaboration with SEDA, these shears meet the specific needs of recycling operations.

The optionally available mobile stands facilitates the transport of the shears and the power unit, enhancing user-friendliness. This makes handling saferand reduces the risk of injury or damage.

Bookmark
Optimally paired with a mobile device
Safety interlock compliant with EN 13204
360° adjustable and removable handle grip
Compact design
Special blade shape with multiple cutting notches
Perfect size

Technical Data

SetRSX105RSX130RSX165RSU180RSU210 Plus
Order NumberC-50446C-50335C-50349C-50425C-50426
Opening width105 mm 130 mm165 mm180 mm210 mm
Cutting force290 kN480 kN642 kN903 kN1.050 kN
Max. cutting capacityØ 22 mmØ 26 mmØ 38 mmØ 35 mmØ 43 mm
Nominal pressure70 MPa55 MPa70 MPa70 MPa70 MPa
Test pressure84 MPa70 MPa84 MPa84 MPa84 MPa
Weight9,3 kg15,4 kg16,3 kg16,9 kg19,8 kg
